Magnetic AutoControl ACCPRO-L-RC01240 Right-Hand Barrier Gate w/ 12' VarioBoom Arm (White)
The Magnetic AutoControl ACCPRO-L-RC01240 is a right-handed barrier gate opener featuring a 12 ft VarioBoom, MHTM MicroDrive motor, and integrated MGC Pro controller in a white powder-coated aluminum housing.
Overview
The Magnetic AutoControl ACCPRO-L-RC01240 delivers reliable access control for wide lanes at industrial sites, residential buildings, and small parking areas. It combines the MHTM MicroDrive maintenance-free drive unit — which integrates the motor, motor control, and gearing into one compact unit — with the MGC Pro controller featuring an LCD display and programmable I/O. The included 12 ft VarioBoom features a foam edge for pedestrian protection and improves barrier visibility. The white powder-coated aluminum housing is rated IP 54 and is UL & CSA certified.
Key Features
- 4.0-second open and close speeds with adjustable opening and closing times
- MHTM MicroDrive — high-torque, maintenance-free motor engineered for severe weather conditions including heavy wind and snow
- MGC Pro controller with LCD display, programmable I/O, selectable auto-open on power failure, and multiple open/close speeds
- EN 13849 compliant MGC Pro control unit
- Integrated dual-channel loop detector included
- 12 ft VarioBoom with foam edge for pedestrian protection
- Rated for 10 million opening and closing cycles
- 2-year warranty
- Maximum power consumption of 25W
Specifications
- Model: ACCPRO-L-RC01240
- Barrier Width: Maximum 12 ft (3.6 m)
- Opening/Closing Time: 4.0 seconds
- Cycle Rating: 10 million cycles
- Drive Technology: MHTM MicroDrive maintenance-free motor
- Input Voltage: 110/115/120 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 3 Phase); 220/230/240 AC (60 Hz, 1 Phase); 230 AC (50 Hz, 1 Phase)
- Frequency: 50 / 60 Hz
- Max Power Consumption: 25 W
- Protection Class: IP 54
- Temperature Range: -22°F to +122°F
- Dimensions (W x D x H): 12" x 14" x 36"
- Weight (without boom): 88 lbs
- Housing: White powder-coated aluminum
- Certifications: UL & CSA
The Magnetic AutoControl ACCPRO-L-RC01240 is a high-cycle, all-weather barrier gate solution built for dependable performance in demanding access control applications.
