AES EL00C-RAD-KLT Commercial eLoop, Presence Mode, eTrans200

Overview

The AES EL00C-RAD-KLT Commercial Loop Kit delivers wireless vehicle detection purpose-built for commercial environments. Operating in presence mode, it keeps gates and barriers open when longer vehicles are detected over the sensing area, reducing interruptions and collision risk. The kit includes the e-Loop unit, e-Trans200 transceiver, magnet, and concrete fixing bolts, everything needed for a quick and easy installation without complex wiring.

Key Features

• Dual sensor technology: Magnetic field and Radar detection
• Presence mode: holds gate or barrier open while vehicle occupies detection area
• Quick and easy wireless installation
• Range up to 50 yards
• 128-bit high-security encryption
• Compact profile, only 1.1" high x 8.6" diameter (IP68 rated)
• Made of high-impact plastic with a 10 tonne static load limit
• 10,600 mA battery providing up to 6–10 years of battery life
• Unique lock-out feature allowing lock-out of entry buttons, e-Loops, and keypads via the e-Remote
• Ability to delete individual remote devices
• Test mode for relay outputs, signal strength, and interference checking
• 200 code storage with remote ID selection
• Selectable ultra-low standby power consumption of 4.5 mA: ideal for solar applications
• 2 relay outputs settable to Pulse, Hold, or Latch mode

e-Trans200 Transceiver Included

• Simple menu functions with LCD display
• High sensitivity 433 MHz / -126 dBm receiver with 20 dBm transmission output
• External SMA connector for optional long-range antenna connection
• Wide input voltage range: 10–36V DC
• Standby current draw: 4.5 mA; Active current draw: 30 mA
• Frequency: 433.39 MHz
• Remote storage: 50 remotes, 4 x e-Loops, 4 x Keypads, 4 x Entry Buttons
• Relay: 1-amp contact rating, COM and N/O connections x 1 relay

Specifications

• Model: EL00C-RAD-KLT
• Brand: AES
• Voltage: 10–36V DC
• Frequency: 433.39 MHz
• Standby Current: 4.5 mA
• Active Current: 30 mA
• Encryption: 128-bit AES
• Detection Range: Up to 50 yards
• Unit Dimensions: 1.1" high x 8.6" diameter
• IP Rating: IP68
• Static Load Limit: 10 tonne
• Battery Life: Up to 6–10 years (10,600 mA battery)
• Code Storage: 200 codes
• Relay Output: 1-amp contact rating, COM and N/O x 1 relay
• Operating Modes: Pulse, Latch, Hold

The AES EL00C-RAD-KLT is a complete, commercial-grade wireless detection kit engineered for reliability, security, and ease of deployment in demanding access control applications.
