ProDataKey Keypad/Reader, 26-bit HID Compatible Wiegand Prox

PDK-RDRKP Keypad Reader – HID® Compatible, 26-Bit Wiegand

The PDK-RDRKP is a keypad-style proximity reader supporting 26-bit Wiegand output and HID®-compatible 125 kHz credentials. This compact unit offers flexible installation and reliable performance for doors, gates, and secured interior spaces.

Key Features

• 125 kHz proximity technology with keypad authentication
• HID® compatible for common credential formats
• Wiegand 26-bit output for universal controller integration
• LED and buzzer indicators for visual/audible feedback
• Surface mount design for quick installation

Technical Specifications

• Read Range: up to 2.5 in. (63 mm)
• Power: 6–14 VDC
• Output Format: Wiegand 26-bit
• Operating Temperature: -40°F to 140°F (-40°C to 60°C)
• Mounting: Single-gang box or wall surface

Applications

Used in commercial and multi-tenant buildings, the PDK-RDRKP provides secure keypad access and credential verification compatible with ProdataKey systems and other Wiegand controllers.
