Transmitter Solutions RAY418ELPW1V 418 MHz Visor Transmitter
SKU
ts-ray418elpw1v
The Transmitter Solutions RAY418ELPW1V is a 418 MHz one-button visor transmitter compatible with the Elite® DT-418, designed for Wiegand 26-bit programmable access control and telephone entry systems.
Overview
The Transmitter Solutions RAY418ELPW1V (Stingray 418ELPW1V) is a programmable visor transmitter operating at 418 MHz. It is designed for use with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems requiring a 418 MHz input. Compatible with the Elite® DT-418 and backed by a 5-year warranty.
Key Features
- Frequency: 418 MHz
- One Button (Green)
- Visor model form factor
- Compatible with Elite® DT-418
- Programmable
- 5-Year Warranty
Specifications
- Supply: 1 Alkaline Battery, 12V type 23A
- Battery Life: 12–18 months
- Current Consumption: 20 mA
- Code Combinations: 65,536
- Facility Codes: 256
- Modulation: AM / ASK
- Range in Free Space: 60–120 yd
- Operating Temperature: -20 ÷ +55 °C
- Overall Dimensions: 3.26 x 1.88 x 0.62 in
- Weight: 1 oz. (20 gr.)
Compatibility
- Elite® DT-418
Also available in a 2-button version: model 418ELPW2V.
