All-O-Matic SL-150-DC-.5-HP Heavy Duty Slide Gate Operator

Overview

The All-O-Matic SL-150-DC-.5-HP was designed to meet the demands of gate installers handling heavy traffic, commercial and industrial heavy gates, and extreme weather conditions. Its heavy duty frame, reliable gearbox, and powerful brushless DC motor make even the most challenging installations manageable. The operator runs on a 24VDC brushless motor and is compatible with 115/230VAC single phase power or 24VDC solar panels.

Key Features

• Continuous duty, brushless DC motor — smooth, quiet, powerful, and requires zero maintenance
• Integrated battery backup with (2) 7Ah 12VDC batteries — up to two weeks of uninterrupted operation during a power outage
• 100 backup cycles on a 1,000 lb. gate
• Programmable relay and leaf delay via control board
• Slow start/stop algorithm
• Solar power capability
• Includes 2 photo eyes
• Emergency mechanical foot pedal release included
• Built-in loop rack
• Made in USA
• 7-year residential / 5-year limited manufacturer warranty
• Additional entrapment prevention devices required

Specifications

• Motor: 24VDC brushless
• Max Gate Weight: 3,000 lbs (1/2 HP)
• Max Gate Length: 60 feet
• Gate Speed: ~12 inches per second
• Power Source: 115/230VAC single phase or 24VDC solar panel
• Operational Voltage: 24VDC
• Duty Cycle: Continuous
• Battery Backup: Integrated, (2) 7Ah 12VDC batteries
• Gearbox Ratio: 30:1 with internal clutch
• Dimensions (W x L x H): 15" x 19.5" x 25"
• Temperature Range: -40° to 160°
• Breaker Requirement: 20 amp dedicated
• Main Sprocket Size: 41B22X1
• Chain Size: 40NP (20 ft. included)
• Gearbox Sprocket: 40B22X1
• Limit Shaft Sprocket: 41B10X5/8
• Emergency Release: Mechanical foot pedal release

The All-O-Matic SL-150-DC-.5-HP delivers commercial-grade slide gate performance with the reliability and durability required for demanding installations.
