Linear MCS109920 1-Channel 110V Gate Receiver
SKU
ln-mcs109920
The Linear MCS109920 is a 1-channel 300 MHz gate receiver with 1,024 DIP-switch programmable codes, a 115V transformer input, and a coaxial antenna for up to 250 ft line-of-sight range.
Overview
The Linear MCS109920 is a 1-channel 110V gate receiver designed for reliable signal reception, including installations inside metal enclosures or signal-restrictive environments. Operating at 300 MHz, it ships with a coaxial antenna for extended range performance.
Key Features
- 1-channel receiver with DIP-switch code programming
- Operates at 300 MHz frequency
- 1,024 programmable codes
- Includes antenna and coaxial connector
- Suitable for metal enclosures or signal-blocking environments
- 115V transformer input
- Relay output: 1 amp @ 30 VAC max
- Range: up to 250 ft (clear line of sight)
Specifications
- Frequency: 300 MHz
- Channels: 1
- Programmable Codes: 1,024 (DIP-switch)
- Input: 115V transformer
- Relay Output: 1 amp @ 30 VAC max
- Range: Up to 250 ft (clear line of sight)
- Dimensions: 5.25" H x 3.625" W x 1.5" D
The Linear MCS109920 delivers consistent gate access performance where reliable signal reception matters most.
