Linear DNR00100 1-Channel Plug-In MegaCode Receiver
The Linear DNR00100 is a 1-channel plug-in MegaCode receiver (MDR/U) that plugs directly into a standard AC outlet and connects to an operator's push-button input via a single two-conductor wire.
Overview
The Linear DNR00100 (MDR/U) is a universal 1-channel plug-in receiver designed to add MegaCode format compatibility to virtually any gate or access control operator. It plugs directly into any standard electrical outlet, with only a single two-conductor wire connection required to the operator's push-button input. The DNR00100 replaces the previous MDR receiver, eliminating the need for a separate power transformer. It is UL Listed and suitable for residential or commercial applications.
Key Features
- Simple plug-in design — connects directly to an AC outlet
- Single two-conductor wire connection to operator push-button input
- MegaCode format with over 1,000,000 codes to minimize code duplication
- RF frequency: 318 MHz
- Stores up to 10 MegaCode transmitters
- One normally open contact output — activates for 0.5 seconds
- Learn mode for simplified programming via a single button press
- UL Listed
- Replaces part number MDR
Specifications
- Model: DNR00100 (MDR/U)
- Brand: Linear
- Channels: 1
- RF Frequency: 318 MHz
- Code Format: MegaCode — 1,000,000+ codes
- Transmitter Memory: Up to 10 MegaCode transmitters
- Output: One normally open contact (activates for 0.5 seconds)
- Power: 110 VAC ±10%, 60 Hz
- Dimensions: 2.52" W x 2.5" H x 1.61" D
- UPC: 93863107870
The Linear DNR00100 is a reliable, professionally installed solution for adding MegaCode receiver capability to virtually any operator.
