All-O-Matic SL-150-DC-1-HP HD Slide Gate Operator
The All-O-Matic SL-150-DC-1-HP is a heavy-duty DC slide gate operator featuring a continuous duty brushless motor, support for gates up to 4,000 lbs and 60 feet, and an integrated 24VDC battery backup system. Includes emergency foot pedal release and 2 photo eyes.
Overview
The All-O-Matic SL-150-DC-1-HP was designed to meet the demands of gate installers who need an operator capable of handling heavy traffic, commercial and industrial heavy gates, and extreme weather conditions. Its heavy-duty frame, reliable gearbox, and powerful brushless DC motor make even the most challenging installations manageable. The 1 HP motor is capable of moving gates up to 4,000 lbs and 60 feet in length.
Key Features
- Continuous duty 24VDC brushless motor — smooth, quiet, powerful, and zero maintenance
- Gate speed of approximately 12 inches per second
- Integrated 24VDC battery backup with (2) 7Ah 12VDC batteries — up to two weeks of uninterrupted operation during a power outage
- Battery backup capacity: 100 cycles on a 1,000 lb. gate
- Compatible with 115/230VAC single phase power or 24VDC solar panel
- Control board with programmable relay and leaf delay, slow start/stop algorithm, and solar power capability
- Includes emergency mechanical foot pedal release and built-in loop rack
- Includes 2 photo eyes
- Gearbox ratio: 30:1 with internal clutch
- Operating temperature range: -40° to 160°
- Made in USA
- Additional entrapment prevention devices required
Specifications
- Max Gate Weight: 4,000 lbs (1 HP)
- Max Gate Length: 60 feet
- Motor: 24VDC brushless, continuous duty
- Gate Speed: ~12 inches per second
- Power Source: 115/230VAC single phase or 24VDC solar panel
- Operational Voltage: 24VDC
- Battery Backup: Integrated, (2) 7Ah 12VDC batteries
- Gearbox Ratio: 30:1 with internal clutch
- Dimensions (W x L x H): 15" x 19.5" x 25"
- Temperature Range: -40° to 160°
- Breaker Requirement: 20 amp dedicated
- Main Sprocket Size: 41B22X1
- Chain Size: 40NP (20 ft included)
- Gearbox Sprocket: 40B22X1
- Limit Shaft Sprocket: 41B10X5/8
- Warranty: 7-year residential / 5-year commercial limited manufacturer warranty
- Emergency Release: Mechanical foot pedal release
The All-O-Matic SL-150-DC-1-HP delivers industrial-grade performance with the reliability and low maintenance of brushless DC technology — built for demanding residential and commercial slide gate applications.
