Transmitter Solutions DOLKPS1KB Stand Alone Ped Mount Keypad
SKU
ts-dolkps1kb
The Transmitter Solutions DOLKPS1KB is a stand alone post mount keypad supporting 1,000 user PINs and 50 visitor codes, housed in a cast aluminum, powder coated enclosure with an IP 66 rated weatherproof design.
Overview
The Transmitter Solutions DOLKPS1KB is a stand alone post mount keypad engineered for reliable access control. Its cast aluminum external housing with powder coat finish and IP 66 weatherproof rating make it suited for demanding outdoor environments. Metal back-lit keys and security screws add both usability and tamper resistance.
Key Features
- Vandal Resistant construction
- Weatherproof — IP 66 Rated
- Metal Back-Lit Keys
- Supports 4–8 digit PINs
- Stand Alone Keypad — no controller required
- Security Screws included
- 1,000 User PINs
- 50 Visitor Codes — programmable for one-time use or time-limited access
Specifications
- Dry Contact: 50 mA / 24 VDC
- Operating Voltage: 12–24 VDC, auto adjusting
- Operating Current: 50 mA (Quiescent) to 150 mA (3 Relay Active)
- Temperature Rating: -4°F to 158°F
- Humidity: 5–95% relative humidity, non-condensing
- Dimensions: 4-7/8" (H) x 3-1/8" (W) x 2-1/8" (D) inches
- Weight: 19.4 oz
- Housing: Cast aluminum external housing, powder coated
- Face Plate Material: 1/16 inch stainless steel
The Transmitter Solutions DOLKPS1KB delivers a robust, feature-rich keypad solution built to perform in challenging outdoor conditions.
