DoorKing 1602-590 1HP Wedge Barrier Gate Operator
DKO-1602-590 – Genuine DoorKing 1602 barrier gate operator with 1 HP motor, 60:1 oil bath gear reduction, and ~5.5 second operation. Designed for wide-lane, limited-use security applications.
The DKO-1602-590 is a genuine DoorKing 1602 Parking Control Barrier Gate Operator designed for limited-use, high-security traffic control applications. This operator is commonly used in conjunction with DoorKing wedge barrier systems to control wide traffic lanes up to 27 feet.
The Model 1602 features a 60:1 worm gear reduction system running in a continuous oil bath, delivering smooth, reliable performance. The barrier arm rotates 90° in approximately 5.5 seconds, making it suitable for low-cycle environments such as prisons, airport security areas, and industrial facilities.
The housing is constructed from G90 galvanized steel with a durable white finish and is rated NEMA 4X for enhanced environmental protection. The unit includes magnetic electronic limit controls, programmable switching, a built-in On/Off power switch, and a selectable warning beeper.
Key Specifications:
• Motor: 1 HP continuous-duty AC motor
• Speed: 90° rotation in ~5.5 seconds
• Gear Reduction: 60:1 worm gear, continuous oil bath
• Maximum Lane Width: 27 ft
• Arm Types: Aluminum arms (20 ft, 24 ft, 27 ft) / Wood (20 ft)
• Voltage: 115 / 230 / 460 VAC
• Class of Operation: II, III, IV
• Housing: G90 galvanized steel, NEMA 4X
• Environmental Rating: 10°F to 140°F
• Shipping Weight: Approx. 160–180 lb
• Listings: ETL Listed
Safety & Options:
The 1602 supports optional DoorKing safety and convenience features including the DKS Pedestrian Protection System, heater kits for cold climates, DC-powered backup drive systems, and lighted aluminum signal arms.
Verify compatibility with wedge barrier systems and installation requirements prior to ordering.
