Linear DNT00017A 2 Channel Delta Visor Transmitter

Overview

The Linear DNT00017A is a two-button, two-channel Delta visor transmitter designed to independently activate two Delta-3 receivers. It operates at 310 MHz and is powered by a 9-volt battery. A removable visor mounting clip is included. Model number: DT 2A.

Key Features

• Activates two Delta-3 receivers independently
• Two buttons, two channels
• Test/operate LED included
• Visor mounting clip supplied
• Code selection via dip switches

Specifications

• RF Frequency: 310 MHz
• Power: 9-volt battery
• Codes: 256 (set by dip switches)
• Dimensions: 2.16" W x 3.75" H x .95" D
• Part Number: DNT00017A
• Model Number: DT 2A
• UPC: 93863103421

Compatibility

• Compatible with Delta-3 receivers

The Linear DNT00017A is a reliable two-channel visor transmitter for professional access control installations.
