Magnetic AutoControl DM02 Loop Detector
The Magnetic AutoControl DM02 is a 2-channel loop detector that plugs directly into the MGC controller to monitor two induction loops and prevent the barrier boom from closing on a vehicle.
Overview
The Magnetic AutoControl DM02 is a 2-channel loop detector module that plugs directly into the MGC controller. It enables monitoring of two induction loops, ensures secure integration in the overall system, and prevents the barrier's boom from closing on a vehicle. A second loop detector can also be used to monitor shadow loops for added safety and security.
Key Features
- Monitors two induction loops simultaneously
- Plugs directly into the MGC controller for easy installation
- 10 sensitivity levels per channel
- 2 frequency ranges (high/low) per channel
- Screw terminal connector type
- Prevents barrier boom from closing on a vehicle
Specifications
- Number of Channels: 2
- Current Consumption: 50 mA
- Inductance Range: 70 to 500 µH
- Sensitivity Levels per Channel: 10
- Frequency Ranges per Channel: 2 (high/low)
- Connector Type: Screw terminals
Compatibility
The DM02 is designed to plug directly into the Magnetic AutoControl MGC controller. Every Magnetic AutoControl barrier opener has a loop detector built-in; the DM02 can be added as a second loop detector for expanded monitoring capability.
Order the Magnetic AutoControl DM02 today for a straightforward, plug-in upgrade to your barrier's loop detection system.
