LiftMaster HDSW24UL 24VDC Heavy-Duty Swing Gate Operator
The LiftMaster HDSW24UL is a heavy-duty swing gate operator designed for commercial and industrial applications, capable of handling gates up to 22 feet long and 2,800 lbs with 24VDC brushless motor technology and myQ smart controls.
LiftMaster HDSW24UL Heavy-Duty Swing Gate Operator
The LiftMaster HDSW24UL is a reliable, heavy-duty swing gate operator built for commercial and industrial applications. Designed to handle demanding environments, it supports gates up to 22 feet long and 2,800 lbs. For higher-capacity needs, an optional long arm allows operation of gates up to 4,500 lbs.
Powered by a 24VDC brushless motor, the HDSW24UL delivers smooth, consistent performance with reduced wear and long-term reliability. Integrated myQ® technology provides enhanced control and monitoring, making it a smart solution for secure, high-traffic access points.
Key Features
- Heavy-duty swing gate operator for commercial and industrial use
- Handles gates up to 22 ft long and 1500 lbs
- Optional long arm supports gates up to 4,500 lbs
- 24VDC brushless motor for efficient, long-lasting performance
- Built-in myQ® technology for smart control and monitoring
- Wireless dual gate communication eliminates trenching
Maximum Gate Capacities
Standard Arm:
- 14 ft: 2,800 lbs
- 18 ft: 2,200 lbs
- 22 ft: 1,500 lbs
Long Arm (Optional):
- 14 ft: 4,500 lbs
- 16 ft: 3,750 lbs
- 18 ft: 3,250 lbs
- 20 ft: 2,750 lbs
- 22 ft: 2,500 lbs
Included Accessories
- LMRRUL Monitored Retro Reflective Photo Eye
Technical Specifications
- Power Input: 120/240VAC single-phase
- Motor: 24VDC brushless motor
- Operating Temperature: -4°F to 140°F (-20°C to 60°C)
Dimensions
- Height: 28.04"
- Width: 16.37"
- Depth: 19.59"
Why Choose the LiftMaster HDSW24UL?
- Battery Backup: Provides up to 45 cycles during power outages
- Adjustable Speed: Gate opening times range from 13 to 36 seconds
- Wireless Communication: Easily syncs dual gates without additional wiring
FAQs
What is the maximum gate size and weight?
It supports gates up to 22 feet long or 2,800 lbs. With the optional long arm, it can handle up to 4,500 lbs.
Does it have a battery backup?
Yes, it includes a battery backup for reliable operation during power outages.
