LiftMaster LA500 Linear Actuator Single Arm Package

LiftMaster LA500PKGUL Swing Gate Operator Package

Overview

The LiftMaster LA500PKGUL is a 24VDC residential and light commercial swing gate operator designed for reliable performance across a wide range of applications. Engineered for durability and consistent operation, this linear actuator system is ideal for both single and dual gate installations when paired with the appropriate accessories.

This package includes the control box, LA500DC primary actuator arm, LMRRUL monitored reflective photo eye, mounting hardware, and two 7Ah batteries for integrated battery backup functionality.

Key Features

• 24VDC Operation: Efficient DC-powered system designed for residential and light commercial use.
• Battery Backup Included: Includes (2) 7Ah batteries to maintain operation during power outages.
• High Duty Cycle: Rated for up to 300 cycles per day.
• Smart Connectivity: MyQ® enabled for remote monitoring and control.
• Advanced Diagnostics: MyQ diagnostics provide system status and troubleshooting insights.
• Wide Compatibility: Supports UL usage classifications I, II, III, and IV.

Specifications

• Model: LA500PKGUL
• Brand: LiftMaster
• Voltage: 24VDC
• Power Input: AC / DC
• Application: Residential / Light Commercial
• Operator Duty Rating: 300 cycles per day
• Operating Temperature: -4°F (-20°C) to 140°F (60°C)
• UL Usage Classification: Class I, II, III, IV
• Battery Backup: Yes (2 included)
• Code Type Compatibility: Security+ 2.0
• Motor Type: DC Residential / Light Commercial Duty

Recommended Gate Capacities

• Up to 8 ft: 1,600 lbs
• Up to 12 ft: 1,200 lbs
• Up to 16 ft: 800 lbs
• Up to 18 ft: 600 lbs

Note: Gate capacity ratings do not account for wind load, gate construction, or site conditions. Operating near maximum capacity is not recommended.
