Transmitter Solutions DOLKWP300-318 Dual Frequency Wireless
The Transmitter Solutions DOLKWP300-318 is a stand-alone dual frequency wireless keypad operating on 300 MHz and 318 MHz, featuring a stainless steel faceplate, IP65 rating, and capacity for up to 99 individual 4-digit codes.
Overview
The Transmitter Solutions DOLKWP300-318 is a stand-alone dual frequency wireless keypad designed for outdoor or indoor use. It operates on both 300 MHz and 318 MHz frequencies and stores up to 99 individual 4-digit access codes. Built with a stainless steel 304 faceplate and an ABS shell, it carries an IP65 (NEMA 4) weather resistance rating and is powered by battery or hardwired supply.
Key Features
- Dual frequency operation: 300 MHz Multicode® 10-dip switch and 318 MHz 9-dip switch
- Compatible with Allstar® 9931 and Heddolf® P220
- Stainless steel 304 faceplate
- Rubber backlit keys
- Holds up to 99 individual 4-digit codes
- Hard wired with optional relay
- IP65 (NEMA 4) rated for outdoor or indoor installation
- 1-year battery life under normal use
Specifications
- Frequencies: 300 MHz / 318 MHz
- User Capacity: 99 — 4-digit PINs
- IP Rating: IP65 (NEMA 4)
- Faceplate Material: Stainless steel 304
- Housing Material: ABS Shell
- Operating Voltage: 9–24VDC (battery or powered) — 500mA
- Temperature Rating: -40°F to 158°F
- Dimensions: 4-1/2" x 3-1/2" x 2-3/16"
- Weight: 8.8 oz
- Battery Life: 1 year (normal use)
Compatibility
- 300 MHz: Multicode® 10-dip switch systems
- 318 MHz: Allstar® 9931, Heddolf® P220
The Transmitter Solutions DOLKWP300-318 delivers reliable dual-frequency wireless access control in a weather-resistant, professional-grade enclosure.
