Nationwide Industries TROLLEY-M4S Slide Gate Trolley
The Nationwide Industries TROLLEY-M4S is a cast steel 4-wheel trolley designed as an integral component of the Internal Track Slide Gate System, compatible with aluminum slide gate tracks.
Overview
The Nationwide Industries TROLLEY-M4S is a cast steel 4-wheel trolley and an integral part of the Internal Track Slide Gate System. Designed to fit all aluminum slide gate tracks, these trolleys are mounted to support posts using Truck Hanger Brackets. The trolleys remain stationary while riding inside the extruded aluminum track integrated into the gate.
Key Features
- Cast steel body construction
- 4-wheel design for stable gate support
- Mounts to support posts via Truck Hanger Brackets
- Compatible with all aluminum slide gate tracks in the Internal Track Slide Gate System
Specifications
- Horizontal Wheels O.D.: 2.125"
- Vertical Wheels O.D.: 2.045"
- Body Material: Cast Steel
Compatibility
The TROLLEY-M4S is designed to fit all Nationwide Industries aluminum slide gate tracks. A typical internal track slide gate system includes one track, two slide gate trolleys, two truck hanger brackets, two bottom roller guides, a stop bracket, and a latch.
The Nationwide Industries TROLLEY-M4S delivers the reliability and precision needed for a complete internal track slide gate installation.
