FAAC 104202125 400 CBAC EG Swing Gate Operator

Overview

The FAAC 400 CBAC EG (model 104202125) is a long hydraulic swing gate operator suited for residential, apartment, subdivision, condo, commercial, and industrial applications. Supplied as operator only, it can be used to convert an existing single kit into a dual Primary/Secondary (bi-parting) configuration or serve as a direct replacement operator. It handles swing gates up to 18 ft (5.5 m) in length and 1,500 lb (680 kg) in weight, and is compatible with both left-hinged and right-hinged gates.

Key Features

• Wide application range from residential to heavy industrial gates
• Hydraulic locking of the gate in open and/or closed positions
• Quiet operation
• Self-lubricating for extended service life
• Key-protected manual release
• Thermal motor protection at 248°F (120°C)
• Protection class IP 55
• UL325 compliant — Class I, Class II, Class III, Class IV
• Compatible with left-hinged and right-hinged gates
• 90-degree maximum opening angle

Specifications

• Input Voltage: 110/115/120 VAC (60 Hz, 1 Phase)
• Power: 220 W
• Current: 2 A
• Motor Rotation Speed: 1,400 r.p.m.
• Thrust Capacitor: 25 uF
• Operating Ambient Temperature: 4°F to 131°F (-20°C to +55°C)
• Dimensions: 50.6 x 4.4 x 3.3 in (1,285 x 113 x 85 mm)
• Maximum Leaf Length: 18 ft (5.5 m)
• Maximum Leaf Weight: 1,500 lb (680 kg)
• Thrust Force: 1,045 lbf (465 daN)
• Pump Flow Rate: 1.5 l/min
• Rod Extension Speed: 0.6 in/sec (1.5 cm/sec)
• Effective Rod Stroke: 15 in (380 mm)
• Use Frequency: 50 cycles per hour
• Oil Type: Regular Oil
• Color: Stainless Steel

Compatibility

• Operator only — includes no control board or accessories
• Use to expand a single kit into a dual Primary/Secondary (bi-parting) setup, or as a replacement operator
• Part of the FAAC 400 CBAC EG series

The FAAC 104202125 delivers reliable, heavy-duty hydraulic swing gate operation across a wide range of residential and commercial installations.
