FAAC 1042011_5 Hydraulic Swing Gate Opener Kit 230V
The FAAC 1042011_5 is a 230V hydraulic swing gate opener kit engineered for gates up to 16 ft and 1,300 lbs, delivering up to 70 cycles per hour with quiet, self-lubricated operation.
Overview
The FAAC 1042011_5 400 CBAC Standard Basic Single Kit is a commercial-grade hydraulic swing gate operator designed for heavy-duty residential, commercial, and industrial applications. Built to handle gates up to 16 feet long and 1,300 pounds, it combines quiet hydraulic performance with high-frequency capability of up to 70 cycles per hour. The kit ships with everything needed for a single-gate installation, and a second operator can be added to configure a primary/secondary bi-parting dual swing gate system. Replaces part number 1042011.5+.
Kit Includes
- (1) 400 CBAC Operator
- (1) 455D Control Board — 230V
- (1) 14" x 16" Pre-Wired Enclosure
- (1) Receiver — 433 RC Plug-In
- (2) 4-Channel Transmitters — XT4 433 RC
Key Features
- Hydraulic system suitable for residential to industrial gates
- Quiet and powerful operation supporting gates up to 1,300 lbs per leaf
- Manual key-release for override access
- Hydraulic locking in open and/or closed positions
- Self-lubricating drive system extends component life
- Thermal protection on motor: 248°F (120°C)
- Protection Class: IP 55
- UL325 Compliant: Class I, Class II, Class III, Class IV
- Compatible with left-hinged and right-hinged gates
Specifications
- Actuator Input Voltage: 220/230/240 AC (60 Hz, 1 Phase)
- Controller Input Voltage: 220/230/240 AC (60 Hz, 1 Phase)
- Power: 220 W
- Current: 1 A
- Motor Rotation Speed: 1,400 r.p.m.
- Thrust Capacitor: 25 uF
- Operating Ambient Temperature: 4°F to 131°F (−20°C to +55°C)
- Dimensions: 40.5 x 4.4 x 3.3 in (1,031 x 113 x 85 mm)
- Maximum Leaf Length: 16 ft (4.9 m)
- Maximum Leaf Weight: 1,300 lb (589 kg)
- Thrust Force: 1,390 lbf (620 daN)
- Pump Flow Rate: 1 l/min
- Rod Extension Speed: 0.4 in/sec (1 cm/sec)
- Effective Rod Stroke: 10.25 in (260 mm)
- Use Frequency: 70 cycles/hour
- Maximum Opening Angle: 90 degrees
- Oil Type: Regular Oil
Compatibility
- To convert to a dual swing gate system, add a second operator: 400 CBAC Standard Gate Operator Only (part number 1042011)
The FAAC 1042011_5 delivers the reliability and hydraulic performance demanded by high-cycle, heavy-gate environments — backed by a complete single-kit package ready for installation.
