FAAC 104201125 Swing Gate Operator
The FAAC 104201125 is a 115V hydraulic swing gate operator handling gates up to 16 ft long and 1,300 lbs. Includes operator only — ideal as a replacement or to build a dual Primary/Secondary bi-parting kit.
Overview
The FAAC 104201125 is a 115V standard hydraulic swing gate operator suited for apartment, subdivision, commercial, condo, industrial, and residential applications. It operates swing gates up to 16 feet long and 1,300 lbs, and is supplied as operator only. Use it as a replacement operator or to convert a single kit into a dual Primary/Secondary (bi-parting) configuration. The unit is UL325 compliant, rated Class I, Class II, Class III, and Class IV, and supports both left-hinged and right-hinged gates.
Key Features
- Quiet hydraulic operation
- Hydraulic locking of the gate in open and/or closed positions
- Self-lubricating for long service life
- Key protected manual release
- Thermal protection on motor at 248°F (120°C)
- Protection class IP 55
- Wide range of use from residential to heavy industrial gates
- 90-degree maximum opening angle
Specifications
- Input Voltage: 110/115/120 AC (60 Hz, 1 Phase)
- Power: 220 W
- Current: 2 A
- Motor Rotation Speed: 1400 r.p.m.
- Thrust Capacitor: 25 uF
- Operating Ambient Temperature: 4°F to 131°F (-20°C to +55°C)
- Dimensions: 40.5 x 4.4 x 3.3 in (1,031 x 113 x 85 mm)
- Maximum Leaf Length: 16 ft (4.9 m)
- Maximum Leaf Weight: 1,300 lb (589 kg)
- Thrust Force: 1,390 lbf (620 daN)
- Pump Flow Rate: 1 l/min
- Rod Extension Speed: 0.4 in/sec (1 cm/sec)
- Effective Rod Stroke: 10.25 in (260 mm)
- Use Frequency: 70 cycles per hour
- Color: Stainless Steel
- Oil Type: Regular Oil
Compatibility
- Compatible with left-hinged and right-hinged swing gates
- Can be used as a Primary operator or added as a Secondary operator for bi-parting gate configurations
Order the FAAC 104201125 for a reliable, hydraulic swing gate solution backed by FAAC's proven engineering.
