FAAC 1042011677 Hydraulic Swing Gate Operator 230V Arctic
The FAAC 1042011677 is a 230V hydraulic swing gate operator with Arctic oil, supporting gates up to 16 ft and 1,300 lbs. Supplied as operator only — ideal as a replacement or to convert a single kit into a dual primary/secondary bi-parting configuration.
Overview
The FAAC 1042011677 is the 400 CBAC Standard hydraulic swing gate operator configured for 220/230/240V AC (60 Hz, 1 Phase) operation and filled with Arctic oil for reliable performance across a wide temperature range. Suitable for apartment, subdivision, commercial, condominium, industrial, and residential applications, this unit ships as operator only — use it as a direct replacement or pair it with an existing operator to create a dual primary/secondary bi-parting gate system.
Key Features
- Wide and versatile range from residential to heavy industrial gates
- Hydraulic lock of the gate in both open and closed positions
- Quiet operation
- Self-lubricating design for long service life
- Key protected manual release
- Arctic oil fill for extended temperature performance
- Supports left-hinged and right-hinged gates
- UL325 compliant — Class I, Class II, Class III, Class IV
Specifications
- Input Voltage: 220/230/240 AC (60 Hz, 1 Phase)
- Power: 220 W
- Current: 1 A
- Motor Rotation Speed: 1400 r.p.m.
- Thrust Capacitor: 25 uF
- Operating Ambient Temperature: -33°F to 165°F (-36°C to +75°C)
- Thermal Protection on Motor: 248°F (120°C)
- Protection Class: IP 55
- Dimensions: 40.5 x 4.4 x 3.3 in (1,031 x 113 x 85 mm)
- Hydraulic Locking: Opening and closing
- Maximum Leaf Length: 16 ft (4.9 m)
- Maximum Leaf Weight: 1,300 lb (589 kg)
- Thrust Force: 1,390 lbf (620 daN)
- Pump Flow Rate: 1 l/min
- Rod Extension Speed: 0.4 in/sec (1 cm/sec)
- Effective Rod Stroke: 10.25 in (260 mm)
- Use Frequency: 70 cycles per hour
- Maximum Opening Angle: 90 degrees
- Oil Type: Arctic Oil
- Operator Kit Type: Operator Only
Compatibility
- Compatible with left-hinged and right-hinged swing gates
- Can be used to convert a single-operator kit into a dual primary/secondary (bi-parting) kit
- Suitable for use as a replacement operator
Order the FAAC 1042011677 with confidence for a proven hydraulic swing gate solution built to perform across residential, commercial, and industrial environments.
