FAAC 1042011 Hydraulic Swing Gate Operator

Overview

The FAAC 1042011 is a 400 CBAC Standard hydraulic swing gate operator designed for a wide range of applications, from residential and condo installations to commercial and heavy industrial sites. Operating on 220/230/240V AC (60 Hz, 1 Phase), it handles swing gates up to 16 ft (4.9 m) in length and 1,300 lbs (589 kg) in weight. This listing includes the operator only — use it as a replacement unit or to convert a single-gate kit into a dual Primary/Secondary (bi-parting) configuration. Compatible with both left-hinged and right-hinged gates.

Key Features

• Handles swing gates up to 16 ft long and 1,300 lbs
• Hydraulic locking of the gate in both open and closed positions
• Quiet operation
• Self-lubricating for extended service life
• Key protected manual release
• Wide application range: residential, apartment, subdivision, condo, commercial, and industrial
• Thermal protection on motor: 248°F (120°C)
• Protection class: IP 55
• UL325 compliant — Class I, Class II, Class III, Class IV
• Color: Stainless Steel
• Oil type: Regular Oil
• Maximum opening angle: 90 degrees

Specifications

• Input Voltage: 220/230/240V AC (60 Hz, 1 Phase)
• Power: 220 W
• Current: 1 A
• Motor Rotation Speed: 1400 r.p.m.
• Thrust Capacitor: 25 uF
• Operating Ambient Temperature: 4°F to 131°F (-20°C to +55°C)
• Dimensions: 40.5 x 4.4 x 3.3 in (1,031 x 113 x 85 mm)
• Maximum Leaf Length: 16 ft (4.9 m)
• Maximum Leaf Weight: 1,300 lb (589 kg)
• Thrust Force: 1,390 lbf (620 daN)
• Pump Flow Rate: 1 l/min
• Rod Extension Speed: 0.4 in/sec (1 cm/sec)
• Effective Rod Stroke: 10.25 in (260 mm)
• Use Frequency: 70 cycles per hour
• Hydraulic Locking: Opening and closing

Compatibility

• Can be paired to create a dual Primary/Secondary (bi-parting) swing gate kit
• Compatible with left-hinged and right-hinged gates

The FAAC 1042011 delivers reliable hydraulic performance for demanding swing gate applications across a broad range of installation types.
