FAAC 1044682_5 Hydraulic Swing Gate Opener Kit
The FAAC 1044682_5 is a 115V hydraulic swing gate opener kit supporting gates up to 10 ft long and 900 lbs, with self-lubricating hydraulic drive and UL 325 compliance.
Overview
The FAAC 1044682_5 402 CBC Single Kit delivers quiet, reliable hydraulic actuation for residential swing gates up to 10 feet in length and 900 pounds (410 kg). Running on 110/115/120V AC (60 Hz, 1 Phase), this kit features a self-lubricating hydraulic drive and hydraulic locking in the closed position. It is UL 325 compliant for Class I, II, III, and IV applications and is compatible with both left-hinged and right-hinged gates. Replaces part number 1044682.5+.
Kit Includes
- (1) 402 CBC Operator
- (1) 455D Control Board — 115V
- (1) 14" x 16" Pre-Wired Enclosure
- (1) Receiver — 433 RC Plug-In
- (2) 4-Channel Transmitters — XT4 433 RC
Key Features
- Self-lubricating hydraulic drive for quiet, low-maintenance operation
- Hydraulic locking in the closed position
- UL 325 compliant — Class I, II, III, and IV
- Compatible with left-hinged and right-hinged single swing gates
- Input voltage: 110/115/120V AC (60 Hz, 1 Phase)
- Protection Class: IP 55
Specifications
- Input Voltage: 110/115/120 AC (60 Hz, 1 Phase)
- Controller Voltage: 110/115/120 AC (60 Hz, 1 Phase)
- Power: 220 W
- Current: 2 A (115V)
- Motor Rotation Speed: 1400 r.p.m.
- Rod Extension Speed: 0.5 in/sec (1.3 cm/sec)
- Pump Flow Rate: 1 l/min
- Traction and Thrust Force: 1124 lbf (500 daN)
- Max Gate Weight: 900 lb (410 kg)
- Max Gate Length: 10 ft (3 m)
- Max Opening Angle: 90 degrees
- Usage Frequency: 55 cycles/hour
- Operating Temperature: 4°F to 131°F (-20°C to +55°C)
- Thermal Protection: 248°F (120°C)
- Protection Class: IP 55
- Dimensions: 37.7 x 3.3 x 2.4 in (959 x 85 x 61 mm)
- Oil Type: Regular Oil
- Color: Painted Steel
Compatibility
- To convert to a dual swing gate kit, add a second 402 CBC Operator (part number 1044682)
- Recommended positive stop accessory: Q3554 (Previously: 3554)
- Optional 12 VAC External Relay (Maglock Relay Kit): Q2352 (Previously: 2352)
The FAAC 1044682_5 is a complete, UL 325-compliant single swing gate opener kit built for dependable residential performance.
