FAAC 415 Single Swing Gate Opener Kit
The FAAC 415 Single Swing Gate Opener Kit (10441811_5) is a 24V DC low voltage swing gate opener built for gates up to 15 feet and 700 lbs, with battery backup and UL325 compliance.
Overview
The FAAC 415 Single Swing Gate Opener Kit (10441811_5) delivers dependable, continuous-use performance for residential and light commercial swing gates up to 15 feet long and 700 pounds. Operating on 24V DC, this low voltage actuator package includes battery backup to keep your gate running during power outages. The double-coated die-cast aluminum housing resists the elements, while built-in limit switches and a manual key-protected release make day-to-day use straightforward. This kit meets UL325 Safety Standards and is compatible with both left-hinged and right-hinged gates, with a maximum opening angle of 90 degrees.
Kit Includes
- (1) 415 Operator
- (1) E024U Control Board
- (1) Power Supply
- (1) 14 x 16 Enclosure
- (2) Batteries — 12V 8 Ah
- (1) Receiver 433 RC Plug-In
- (2) 4-Channel Transmitters XT4 433 RC
Key Features
- Low voltage in-axis thrust actuator with continuous use capability
- Built-in limit switches and horizontal cable exit for easy near-ground installation
- Double-coated die-cast aluminum housing for lasting durability
- Manual key-protected release for emergency access
- Includes battery backup for uninterrupted operation during power outages
- Meets UL325 Safety Standards — Class I, Class II, Class III, Class IV
- Compatible with left-hinged and right-hinged gates
Specifications
- Model: 10441811_5
- Actuator Voltage: 24V DC
- Controller Input Voltage: 110/115/120V AC (60 Hz, 1 Phase)
- Power: 70 W
- Current: 3 A
- Thrust: 630 lbf (280 daN)
- Rod Stroke: 15.75 in
- Rod Speed: 0.63 in/sec
- Max Gate Weight: 700 lb
- Max Gate Length: 15 ft
- Max Opening Angle: 90 degrees
- Operating Temperature: -4°F to 131°F
- Use Frequency: Continuous
- Protection Class: IP 54
Compatibility
- To build a Primary/Secondary dual gate setup, add: 415 Gate Operator Only (part number 104418115) and AWG 12 2-Conductor Cable (part number 2197)
- Replaces part number 10441811.5
The FAAC 415 Single Swing Gate Opener Kit 10441811_5 is a complete, ready-to-install solution for reliable single swing gate automation.
