Nationwide Industries ACA-1 42" Access Control Arm with Base

Overview

The Nationwide Industries ACA-1 is a gooseneck-style access control arm with an integrated base, built for pad mounting at vehicle entry points, gate keypads, intercom posts, and drive-thru security checkpoints. Constructed from 2.00" × 2.00" square tube with a 1.15" wall thickness, the arm delivers a total vertical height of 41.00" and a horizontal offset of 13.00" at the top bend.

Key Features

• Gooseneck profile with 13.00" horizontal offset at top bend
• Pad mountable with base plate included
• Constructed from 2.00" × 2.00" square tube
• Suitable for vehicle entry card readers, gate keypads, intercom or speaker posts, and drive-thru or security checkpoint installations
• Mounting hardware for device and pad not included

Specifications

• Total Vertical Height: 41.00"
• Horizontal Offset at Top (bend): 13.00"
• Arm Tube Size: 2.00" × 2.00" square tube
• Arm Wall Thickness: 1.15"
• Weight: 17 lbs
• Bottom Mounting Plate Size: 4.00" × 4.00"
• Bottom Plate Center Hole Diameter: Ø 1.75"
• Bottom Plate Corner Holes: 4× at 0.27" square, inset 0.25" from edge
• Collar/Lip Height Below Bottom Plate: 1.00"
• Top Mounting Plate Size: 5.00" × 5.00"
• Top Plate Center Hole Diameter: Ø 1.75"
• Top Plate Bolt Holes: 4× at Ø 0.75" each
• Top Plate Bolt Hole Pattern Spacing: 3.00" × 3.00"

The Nationwide Industries ACA-1 provides a purpose-built mounting solution for access control equipment in professional installation environments.
