LiftMaster PED4272 Dual-Height Pad-Mount Pedestal

Overview

The LiftMaster PED4272 is a pad-mount gooseneck pedestal designed to serve vehicle entry points that accommodate both standard cars and large trucks. It provides two mounting heights — 42 inches for cars and 72 inches for trucks — on a single post constructed from heavy-duty 2" x 2" 11-gauge square steel tubing with a black powder-coated finish for long-lasting outdoor use.

Key Features

• Dual mounting heights: 42 in for cars and 72 in for trucks
• Pad-mount design for permanent surface installation
• Two universal faceplates with multi-hole configurations for flexible device mounting
• Constructed from 2" x 2" 11-gauge square steel tubing
• Black powder-coated finish for weather resistance and durability
• Rated for outdoor usage
• Suitable for commercial and industrial vehicle entry points

Specifications

• Model: PED4272
• Mount Type: Pad mount
• Mounting Heights: 42 in and 72 in
• Post Dimensions: 2 in x 2 in square steel
• Material: 11-gauge steel
• Finish: Black powder-coated
• Faceplates: Dual universal mounting faceplates
• Application: Gate | Barrier
• Installation Type: Residential | Commercial | Industrial | HOA

Compatibility

• Compatible with keypads, card readers, and intercoms via universal faceplate hole patterns
• Replaces part number G5592

The LiftMaster PED4272 delivers a rugged, dual-height mounting solution for access control devices at sites that serve both standard vehicles and large trucks.
