FAAC 10420012_5 Hydraulic Swing Gate Opener Kit
The FAAC 10420012_5 is a 115V single hydraulic swing gate opener kit rated for gates up to 10 feet and 900 lbs, with UL325 compliance and high-cycle capability of 55 cycles/hour.
Overview
The FAAC 10420012_5 (422 CBAC 115V Single Kit UL325) is a complete hydraulic swing gate opener package built for residential driveways, apartment complexes, and gated entries. Designed for single swing gates up to 10 feet (3 m) and 900 lbs (410 kg), this kit delivers quiet hydraulic operation and handles up to 55 cycles per hour without overheating. It is UL325 compliant for Class I, Class II, Class III, and Class IV applications. This kit can be expanded into a dual swing gate system by adding a second 422 CBAC operator (part number 10420012). Replaces part number 10420012.5+.
Key Features
- Hydraulic operation engineered for high-cycle residential applications
- Quiet gate movement suited for populated residential areas
- Hydraulic lock in both open and closed positions for gate security
- Key-protected manual release for access during power loss
- Self-lubricating components for long service life with minimal upkeep
- Compatible with left-hinged and right-hinged gates
- Expandable to a dual (bi-parting) swing gate system
Kit Includes
- (1) 422 CBAC Operator
- (1) 455D Control Board — 115V
- (1) 14" x 16" Pre-Wired Enclosure
- (1) Receiver — 433 RC Plug-In
- (2) 4-Channel Transmitters — XT4 433 RC
Specifications
- Actuator Input Voltage: 110/115/120 AC (60 Hz, 1 Phase)
- Controller Input Voltage: 110/115/120 AC (60 Hz, 1 Phase)
- Power: 220 W
- Current: 2 A
- Motor Rotation Speed: 1400 r.p.m.
- Rod Extension Speed: 0.5 in/sec (1.3 cm/sec)
- Pump Flow Rate: 1 l/min
- Traction and Thrust Force: 1124 lbf (500 daN)
- Max Gate Weight: 900 lb (410 kg)
- Max Gate Length: 10 ft (3 m)
- Max Opening Angle: 90 degrees
- Usage Frequency: 55 cycles/hour
- Operating Ambient Temperature: 4°F to 131°F (-20°C to +55°C)
- Thermal Protection on Motor Winding: 248°F (120°C)
- Protection Class: IP 55
- Dimensions (L x D x H): 38.8 x 4.7 x 3.3 in (987 x 120 x 85 mm)
- Color: Stainless Steel
- Oil Type: Regular Oil
- UL325 Compliant: Class I, Class II, Class III, Class IV
Compatibility
- Works with left-hinged and right-hinged swing gates
- To convert to a dual gate system, add a second 422 CBAC Operator (part number 10420012)
The FAAC 10420012_5 delivers dependable, low-maintenance hydraulic performance in a complete, UL325-compliant single swing gate kit.
