FAAC 1042001277 Hydraulic Swing Gate Opener Arm
The FAAC 1042001277 is a 422 CBAC hydraulic swing gate opener arm rated for gates up to 10 ft long and 900 lbs, with Arctic Oil and 115V input for residential and light commercial use.
Overview
The FAAC 1042001277 is the 422 CBAC hydraulic swing gate operator arm designed for residential and light commercial applications. Operating on 110/115/120V AC (60 Hz, 1 Phase), this arm handles swing gates up to 10 feet long and 900 lbs, cycling up to 55 times per hour. Filled with Arctic Oil, it is built for a wide operating temperature range and long service life. Use it as a replacement operator or to convert a single kit into a dual Primary/Secondary (bi-parting) configuration. Compatible with both left-hinged and right-hinged gates.
Key Features
- Hydraulic lock of the gate in both opened and closed positions
- Key-protected manual release
- Quiet operation
- Self-lubricating design for long service life
- Arctic Oil fill for cold-weather performance
- Versatile operator for residential and light commercial use
- Compatible with left-hinged and right-hinged swing gates
- UL325 compliant — Class I, Class II, Class III, Class IV
Specifications
- Part Number: 1042001277
- Input Voltage: 110/115/120V AC (60 Hz, 1 Phase)
- Power: 230 W
- Current: 2 A
- Motor Rotation Speed: 1400 r.p.m.
- Rod Extension Speed: 0.5 in/sec (1.3 cm/sec)
- Pump Flow Rate: 1 l/min
- Traction and Thrust Force: 1124 lbf (500 daN)
- Max Gate Weight: 900 lb (410 kg)
- Max Gate Length: 10 ft (3 m)
- Max Opening Angle: 90 degrees
- Usage Frequency: 55 cycles per hour
- Operating Ambient Temperature: -4°F to 131°F (-20°C to +55°C)
- Thermal Protection on Motor Winding: 248°F (120°C)
- Protection Class: IP 55
- Dimensions (L x D x H): 38.8 x 4.7 x 3.3 in (987 x 120 x 85 mm)
- Color: Stainless Steel
- Oil Type: Arctic Oil
- Operator Kit Type: Operator Only
Compatibility
- Left-hinged and right-hinged swing gates
- Can convert a single kit into a dual Primary/Secondary (bi-parting) kit
- Suitable as a replacement operator for existing 422 CBAC installations
The FAAC 1042001277 delivers reliable, hydraulic-powered swing gate operation built to perform in demanding residential and light commercial environments.
