FAAC 1042001277_5 Hydraulic Swing Gate Opener Kit

Overview

The FAAC 1042001277_5 — the 422 CBAC 115V UL Arm (Arctic Oil) Single Kit — delivers quiet, self-lubricating hydraulic performance for swing gate applications at residential homes, condominiums, and light commercial entrances. The kit arrives ready to deploy with a pre-wired enclosure, control board, receiver, and two transmitters included.

Kit Includes

• (1) 422 CBAC Operator
• (1) 455D Control Board – 115V
• (1) 14" x 16" Pre-Wired Enclosure
• (1) Receiver – 433 RC Plug-In
• (2) 4-Channel Transmitters – XT4 433 RC

Key Features

• Versatile hydraulic operator for residential and light commercial applications
• Hydraulic lock of the gate in opened and closed positions
• Key protected manual release
• Quiet operation
• Self-lubricating for long service life
• Arctic oil formulation
• Up to 55 cycles per hour
• 90-degree maximum opening angle
• Compatible with left-hinged and right-hinged gates

Specifications

• Actuator Input Voltage: 110/115/120 AC (60 Hz, 1 Phase)
• Controller Input Voltage: 110/115/120 AC (60 Hz, 1 Phase)
• Power: 230 W
• Current: 2 A
• Motor Rotation Speed: 1400 r.p.m.
• Rod Extension Speed: 0.5 in/sec (1.3 cm/sec)
• Pump Flow Rate: 1 l/min
• Traction and Thrust Force: 1124 lbf (500 daN)
• Max Gate Weight: 900 lb (410 Kg)
• Max Gate Length: 10 ft (3 m)
• Usage Frequency: 55 cycles per hour
• Operating Ambient Temperature: -4°F to 131°F (-20°C to +55°C)
• Thermal Protection on Motor Winding: 248°F (120°C)
• Protection Class: IP 55
• Dimensions (L x D x H): 38.8 x 4.7 x 3.3 in (987 x 120 x 85 mm)

Compatibility

To convert this single gate kit into a Primary/Secondary (bi-parting) dual gate system, add a second 422 CBAC Operator Only (part number 1042001277).

The FAAC 1042001277_5 is a complete, field-ready solution engineered for reliable swing gate automation.
