FAAC 10420012 Hydraulic Swing Gate Operator

Overview

The FAAC 10420012 is a 422 CBAC hydraulic swing gate operator designed for residential and light commercial applications. It accommodates swing gates up to 10 feet in length and 900 lbs in weight, delivering up to 55 cycles per hour. Use it to convert a single-gate kit into a dual Primary/Secondary (bi-parting) configuration, or as a direct replacement operator. The unit uses regular oil and operates on 110/115/120 VAC (60 Hz, 1 Phase).

Key Features

• Versatile hydraulic operator for residential and light commercial use
• Hydraulic lock of the gate in both opened and closed positions
• Key-protected manual release
• Quiet operation
• Self-lubricating for long service life
• Compatible with left-hinged and right-hinged gates
• UL325 compliant — Class I, Class II, Class III, Class IV

Specifications

• Input Voltage: 110/115/120 AC (60 Hz, 1 Phase)
• Power: 220 W
• Current: 2 A
• Motor Rotation Speed: 1400 r.p.m.
• Rod Extension Speed: 0.5 in/sec (1.3 cm/sec)
• Pump Flow Rate: 1 l/min
• Traction and Thrust Force: 1124 lbf (500 daN)
• Max Gate Length: 10 ft (3 m)
• Max Gate Weight: 900 lb (410 kg)
• Max Opening Angle: 90 degrees
• Usage Frequency: 55 cycles per hour
• Operating Ambient Temperature: 4°F to 131°F (-20°C to +55°C)
• Thermal Protection on Motor Winding: 248°F (120°C)
• Protection Class: IP 55
• Dimensions (L x D x H): 38.8 x 4.7 x 3.3 in (987 x 120 x 85 mm)
• Color: Stainless Steel
• Oil Type: Regular Oil

Compatibility

• Operator Only — no control board or accessories included
• Use to expand a single-gate kit into a dual Primary/Secondary (bi-parting) setup
• Compatible with left-hinged and right-hinged swing gates

The FAAC 10420012 delivers reliable hydraulic performance for demanding residential and light commercial swing gate installations.
