National Loop P-NL26-18-100 Preformed Saw-Cut Inductive Loop
The National Loop P-NL26-18-100 is a 6x12 preformed saw-cut inductive loop with a 100 ft lead, white, featuring one continuous wire throughout the loop turns and lead-in for reliable vehicle detection.
Overview
The National Loop P-NL26-18-100 is a 6x12 preformed saw-cut inductive vehicle detection loop with a 100 ft lead-in, available in white. The lead-in is non-spliced and machine-twisted, using polypropylene-wrapped copper wire. This continuous-length design fits in a 1" deep saw cut, reducing installation time and labor while eliminating the guesswork of determining the number of turns needed for optimal read-height. Precisely stacked wires allow sealant to fully encapsulate the loop more effectively than hand-wound alternatives.
Key Features
- One continuous wire throughout loop turns and lead-in — no splices
- Non-spliced, machine-twisted lead-in with polypropylene-wrapped copper wire
- Fits in a 1" deep saw cut
- Precisely stacked wires allow sealant to fully encapsulate the loop
- Reduces guesswork for determining number of turns for optimal read-height
- Optimizes read-height, eliminates faulty signals, and minimizes callbacks
- 100 ft lead-in length
- Color: White
Specifications
- Model: P-NL26-18-100
- Loop Size: 6x12
- Lead Length: 100 ft
- Color: White
- Saw Cut Depth: 1"
- Wire Gauge: 18GA PNL (1/8")
Compatibility
Designed for vehicle detection in conjunction with:
- Access Control
- Parking Barrier Gates
- Gate Operators
- Traffic Signals
- Arming Devices
- Vehicle Counters
The National Loop P-NL26-18-100 delivers professional-grade accuracy and reliability for demanding vehicle detection installations.
