Nationwide Industries ACA-72-B 72" Direct Burial Gooseneck P
SKU
wi-aca-72-b
The Nationwide Industries ACA-72-B is a 72" direct burial gooseneck post featuring a 90° bend with a 13" horizontal offset and a 4" × 4" mounting base plate.
Overview
The Nationwide Industries ACA-72-B is a 72-inch direct burial gooseneck post designed for access control installations. It features a 90° bend at the top with a 13.00" horizontal offset, allowing equipment to be positioned conveniently at the end of the arm. The post mounts via a 4.00" × 4.00" square base plate with a center pass-through hole.
Specifications
- Model: ACA-72-B
- Brand: Nationwide Industries
- Total Length: 72.00"
- Horizontal Offset at Top (Bend): 13.00"
- Rod/Tube Diameter: 2.00"
- Mounting Plate Size: 4.00" × 4.00"
- Center Hole Diameter: 1.75"
- Corner Hole Diameter: 1.00"
- Corner Hole Inset from Edge: 0.25"
The ACA-72-B delivers a purpose-built mounting solution for professional access control installations requiring a direct burial gooseneck post.
