FAAC 108757 750 100° Drive Unit
SKU
faaco-108757
The FAAC 108757 is a 100° drive unit for the FAAC 750 in-ground hydraulic swing gate operator, supporting gates up to 1,700 lb (771 kg) and 13 ft (4 m) with an external lock.
Overview
The FAAC 108757 750 100° Drive Unit is designed to be added to the FAAC 750 in-ground hydraulic gate operator, enabling it to move swing gates through a 100 degree opening angle. Designed and manufactured by FAAC.
Key Features
- 100 degree standard opening angle
- Maximum rotation angle: 118 degrees
- Protection class IP 67 — suitable for in-ground installation
- Handles gates up to 1,700 lb (771 kg)
- Supports leaf lengths up to 13 ft (4 m) with external lock, or 8 ft (2.4 m) without external lock
- Includes drive unit, installation accessories, metal enclosure with stainless steel cover, and extra oil
Specifications
- Opening Angle: 100 degrees
- Maximum Rotation Angle: 118 degrees
- Angle Speed: 7.8 degrees/s
- Effective Torque: 400 lbf.ft (543 Nm)
- Maximum Leaf Length: 13 ft (4 m) with external lock; 8 ft (2.4 m) without external lock
- Maximum Leaf Weight: 1,700 lb (771 kg)
- Protection Class: IP 67
- Part Number: 108757
- UL325 Compliant: Class I, Class II, Class III, Class IV
Compatibility
- Compatible with the FAAC 750 swing gate opener
The FAAC 108757 is a purpose-built drive unit engineered to deliver reliable, high-torque performance for demanding swing gate applications.
