FAAC 107725_5 In-Ground Hydraulic Pump Motor Assembly
The FAAC 107725_5 is a 115V in-ground hydraulic pump motor assembly with enclosure for the 750 CBAC swing gate operator, supporting gates up to 13 ft long and 1,700 lbs per leaf.
Overview
The FAAC 107725_5 is the 750 CBAC in-ground hydraulic pump motor assembly with enclosure, operating at 115V. Designed for below-ground installation, this unit is nearly invisible once installed, offering a cleaner aesthetic suited to artistic and decorative gates. It is well suited for residential applications including condos and single-family homes, and supports a wide range from residential to commercial use. This assembly includes the pump motor and enclosure. Replaces part number 107725.5.
Key Features
- Invisible, in-ground installation with separate drive unit and pump motor
- Quiet operation for noise-sensitive environments
- Self-lubricating design for extended service life
- Hydraulic lock holds the gate securely in both open and closed positions
- Supports swing gates up to 13 ft long and 1,700 lbs per leaf
- Ideal solution for artistic and decorative gates
- Suitable for residential to commercial applications
Specifications
- Input Voltage: 115 VAC (+10% -6%)
- Power: 220 W
- Current: 2A (120V) / 1A (230V)
- Motor Rotation Speed: 1400 r.p.m.
- Pump Flow Rate: 0.75 l/min
- Operating Ambient Temperature: 4°F to 131°F (-20°C to +55°C)
- Thermal Protection on Motor Winding: 248°F (120°C)
- Use Frequency: 45 cycles per hour
- Protection Class: IP 55
- Dimensions: 9.6 x 13.9 x 5.5 in (245 x 353 x 141 mm)
- UL325 Compliant: Class I, Class II, Class III, Class IV
- Operator Type: Swing Gate Operator
Compatibility
115V single leaf gate system requires:
- (1) 750 CBAC Pump Motor Assembly with Enclosure — part number 107725.5
- (1) 100 Degree Drive Unit for 750 — part number 108757
- (1) 455D Control Board with 14 x 16 Enclosure — part number 455D115F.5
- (1) Foundation Plate — part number 737607
- (1) Flexible Hydraulic Hose — part number 390422
- (1) Flex Hose Connector Kit — part number 390421.5
115V dual leaf gate system requires:
- (2) 750 CBAC Pump Motor Assemblies with Enclosures — part number 107725.5
- (2) 100 Degree Drive Units for 750 — part number 108757
- (1) 455D Control Board with 14 x 16 Enclosure — part number 455D115F.5
- (2) Foundation Plates — part number 737607
- (2) Flexible Hydraulic Hoses — part number 390422
- (2) Flex Hose Connector Kits — part number 390421.5
The FAAC 107725_5 delivers reliable, quiet hydraulic performance for demanding swing gate installations.
