FAAC 106753_5 24V In-Ground Swing Gate Opener Kit

FAAC 770 24V Single Basic Kit with E024U — In-Ground Swing Gate Opener

The FAAC 770 24V Single Basic Kit (106753_5) delivers discreet, in-ground gate automation for residential and light commercial driveways. Designed to remain hidden below ground level, the 770 operator preserves the aesthetic appearance of your property while providing reliable, powerful swing gate operation for gates up to 14 feet wide and 1,100 pounds. With optional opening angles of 140° and 180°, this kit offers flexible installation to accommodate a wide range of driveway and entrance configurations.

Key Features

• In-Ground Hidden Installation: The operator mounts below ground inside a support box, keeping hardware out of sight for a clean, unobstructed appearance.
• 24V DC Operation: Low-voltage 24V system for safe, efficient performance with battery backup capability.
• Heavy-Duty Gate Capacity: Supports single swing gates up to 14 feet in length and 1,100 lbs. in weight — ideal for large residential or light commercial entries.
• E024U Control Board: Includes the FAAC E024U electronic control board for precise gate movement programming, safety device integration, and diagnostic functions.
• Flexible Opening Angles: Optional 140° and 180° opening configurations to suit various site requirements.
• Battery Backup Included: Two 12V 8 Ah batteries are included in the kit for continued operation during power outages.
• Plug-In Receiver: Kit includes a 433 MHz RC plug-in receiver for convenient remote access integration.

Kit Includes

• (1) FAAC 770 In-Ground Operator
• (1) Support Box
• (1) Power Supply
• (1) E024U Control Board
• (1) 14 x 16 Enclosure
• (2) 12V 8 Ah Batteries
• (1) 433 MHz RC Plug-In Receiver

Specifications

• Voltage: 24V DC
• Maximum Gate Length: 14 feet
• Maximum Gate Weight: 1,100 lbs.
• Opening Angle: Optional 140° and 180°
• Battery Backup: (2) 12V 8 Ah batteries included
• Control Board: E024U
• Receiver Frequency: 433 MHz
• Enclosure Size: 14 x 16
• Manufacturer SKU: 106753_5 (Previously: 106753.5)

Application Notes

This single operator kit is designed for automating one swing gate leaf. It is well suited for residential driveways, estate entrances, and light commercial applications where a concealed gate operator is desired. The in-ground design is particularly popular in installations where above-ground hardware would detract from the appearance of ornamental or custom gates. For dual swing gate configurations, a second operator and appropriate dual-gate control setup would be required.

FAAC is a globally recognized leader in gate automation, and the 770 series reflects decades of engineering excellence. Built for durability and consistent performance, this kit provides a professional-grade solution that combines powerful operation with discreet, below-ground installation. Trust FAAC quality to deliver reliable access control for years to come.
