FAAC 950 N2 24VDC Automatic Swing Door Operator
The FAAC 950 N2 Automatic Swing Door Operator features a 24 VDC motor with return spring and integrated microprocessor control unit for pedestrian doors.
FAAC 950 N2 Automatic Swing Door Operator
The FAAC 950 N2 Automatic Swing Door Operator (Part Number: 10541512) is a reliable electro-mechanical automated system engineered for pedestrian swing doors. Designed for smooth, consistent operation, this operator combines a powerful 24 VDC motor with a return spring mechanism to deliver dependable door automation in commercial and institutional environments.
At the heart of the 950 N2 is an integrated microprocessor control unit that provides precise speed adjustments, giving installers and facility managers full control over door movement for optimal safety and convenience. The system also includes a USB port for easy firmware updates and streamlined configuration uploads and downloads, making setup and maintenance straightforward.
Key Features
- Electro-Mechanical Operation: Robust electro-mechanical system designed for reliable, long-lasting performance on pedestrian swing doors.
- 24 VDC Motor with Return Spring: Energy-efficient 24 VDC motor paired with a return spring ensures smooth door opening and controlled closing action.
- Integrated Microprocessor Control Unit: Built-in microprocessor allows for accurate and fine-tuned speed adjustments to match specific door and traffic requirements.
- USB Port: Convenient USB connectivity enables firmware updates, configuration uploads, and configuration downloads for easy commissioning and ongoing maintenance.
- Automated Pedestrian Door Solution: Purpose-built for automating pedestrian swing doors in a wide range of commercial, retail, and institutional applications.
Specifications
- Manufacturer: FAAC
- Part Number: 10541512
- Model: 950 N2
- Motor Type: 24 VDC
- Return Mechanism: Return spring
- Control Unit: Integrated microprocessor
- Connectivity: USB port for firmware updates and configuration management
- Application: Pedestrian swing doors
- Operation Type: Electro-mechanical
Compatibility & Application Notes
The FAAC 950 N2 is designed specifically for pedestrian swing door applications. Compatible accessories include the FAAC 950 BM Articulated Pushing Arm (FAAC 390039) and FAAC 950 BM Sliding Arm, which are available separately to complete the installation. Be sure to select the appropriate arm type based on your door configuration and mounting requirements.
This operator is ideal for commercial buildings, office complexes, healthcare facilities, retail stores, and any environment where automated pedestrian door access is required. Its versatile microprocessor control and USB configuration capabilities make it suitable for both new installations and retrofit projects.
Quality & Reliability
FAAC is a globally recognized leader in automated access solutions, and the 950 N2 upholds that reputation with proven electro-mechanical engineering and intelligent control technology. Built to deliver consistent, maintenance-friendly performance over years of daily use, the FAAC 950 N2 Automatic Swing Door Operator is a trusted choice for professionals seeking a dependable pedestrian door automation solution.
