Magnetic AutoControl ACCPRO-L-RCO1510 Right-Hand Barrier Gate w/ 15' VarioBoom Arm (Dark Grey)

Overview

The Magnetic AutoControl ACCPRO-L-RCO1510 is a heavy-duty barrier gate opener built for wide-lane access control at industrial sites, residential buildings, small parking areas, and more. This dark grey operator combines the MGC Pro controller, an MHTM MicroDrive maintenance-free motor, and an included 15 ft VarioBoom in one complete system. The VarioBoom enhances barrier visibility and features a foam edge designed to protect people from harm. The motor, motor control, and gearing are all integrated into one compact drive unit.

Key Features

• 4.0-second open and close speeds
• Adjustable opening and closing times
• Rated for 10 million opening and closing cycles
• MGC Pro control unit with LCD display and programmable I/O
• Selectable auto-open on power failure
• Multiple open and close speeds selectable
• EN 13849 compliant control unit
• Integrated dual-channel loop detector
• Maximum power consumption of 25W
• Dark grey powder-coated aluminum housing
• 2-year warranty

Specifications

• Included Arm Length: 15 ft
• Opening/Closing Time: 4.0 seconds
• Cycle Rating: 10 million cycles
• Drive Technology: MHTM MicroDrive maintenance-free motor
• Max Power Consumption: 25 W
• Input Voltage: 110/115/120 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 3 Phase); 220/230/240 AC (60 Hz, 1 Phase); 230 AC (50 Hz, 1 Phase)
• Frequency: 50 / 60 Hz
• Temperature Range: -22°F to +122°F
• Protection Class: IP 54
• Dimensions (W x D x H): 12" x 14" x 36"
• Weight (without boom): 88 lbs
• Certifications: UL & CSA

What's Included

• MGC Pro Controller with LCD display
• 15 ft VarioBoom barrier boom
• Integrated dual-channel loop detector

The Magnetic AutoControl ACCPRO-L-RCO1510 delivers reliable, high-cycle barrier gate performance across a wide range of access control applications.
