Linear SGEKAC AC Gate Edge Radio Kit Monitored
The Linear SGEKAC is a monitored AC gate edge radio kit that includes one SGET transmitter, one SGER receiver, and one SGACsens sensor. UL325 2016 approved for APeX2 operators.
Overview
The Linear SGEKAC is a monitored AC gate edge radio kit designed for use with automatic gate openers. The kit includes one SGET transmitter, one SGER receiver, and one SGACsens sensor. In a typical installation, the SGET is mounted on a motorized gate, door, or barrier arm and wired to a 10K exterior safety edge sensor, which presents a closed circuit across the connecting wires when an object is contacted during the closing of a gate.
Each transmitter is pre-set at the factory to a unique code — no coding switches are used. The receiver is programmed by sending a signal from the transmitter(s) to be used, storing their codes into memory. The receiver retains its memory even without power and will activate only from memorized transmitters.
The SGACsens AC sensor reliably detects AC motor activation by being in close proximity to — but not electrically connected to — an active motor feed wire.
Key Features
- Works with all 10K monitored gate operators; uses 10K terminated edges
- 2 channels for up to 2 edges and transmitters per receiver
- Low battery alert before failure
- Receiver powered by 12–30 VDC
- 2 output relays
- 10K during normal conditions; shorted during sense or power fail
- Audio and LED feedback for installation and troubleshooting
- Simple setup and programming
- UL325 2016 approved for APeX2 operators
- Hard wired motor sensing for 12–24 volt DC motors
- Non-contact SGACsens module for high voltage AC motors (115–460VAC)
Specifications
- Receiver input voltage: 10.5–30 volts DC
- Relay contact rating: 5 amps @ 32 volts AC/DC, NEC Class 2 circuit
- Channels: 2
- Sensor termination: 10K
- AC motor sensing range: 115–460VAC
Compatibility
- UL325 2016 approved for APeX2 operators
- NSC recommends Miller gate edge sensors with 10K only to ensure full compatibility with all gate edge supervision features — please specify when ordering sensor
The Linear SGEKAC delivers a reliable, factory-coded wireless safety edge solution for monitored gate applications requiring AC motor sensing.
