Altronix AL600ULACM 8-Output 6A Access Power Controller
The Altronix AL600ULACM is a high-capacity access power controller featuring eight independently controlled relay outputs and 6A total output capacity, designed for mid to large-scale access control systems with integrated power supply and battery backup.
AL600ULACM Access Power Controller with Integrated Supply & Charger
The **AL600ULACM** is a higher-capacity access control power controller with embedded power supply and battery charging, designed to support expanded installations. It provides **eight independently controlled relay outputs** and a total output current of **6 A** (shared across circuits). This unit enables you to manage multiple access devices from a single point. Fuses are replaceable :contentReference[oaicite:6]{index=6}
Each output can be individually configured as fail-safe or fail-secure. The onboard charger supports sealed battery backups with seamless switchover when AC is lost. A fire alarm interface (FACP) allows system-wide control during alarm events. The AL600ULACM is ideal for enterprise or multi-door security environments. :contentReference[oaicite:7]{index=7}
Key Features
- Integrated power & control — one unit handles power, switching, and battery backup
- Eight relay outputs — each individually switchable
- 6 A total output capacity supports robust system loads
- Fail-safe / fail-secure per output
- Onboard battery charger & backup switching
- Fire alarm disconnect interface for emergency override
- Compact enclosure design (BC400 series) :contentReference[oaicite:8]{index=8}
Usage & Benefits
The AL600ULACM is designed for mid‑ to large-scale access control systems requiring multiple independently-controlled outputs. It’s especially useful in setups with many doors, locks, or sensors needing individual switching and shared power. Because the power supply is embedded, installation is streamlined and fewer parts are needed. The battery backup and fire interface ensure compliance with safety requirements and uninterrupted operation. :contentReference[oaicite:9]{index=9}
Technical Specifications
- Input: 115 VAC, 60 Hz (typical)
- Output Power: 6 A (shared across outputs) at 12 VDC or 24 VDC (as selected) :contentReference[oaicite:10]{index=10}
- Outputs: 8 independent relay circuits
- Battery Support: Charger built-in, automatic switchover on AC loss
- Fire Alarm Input: Dry contact interface for FACP / emergency control
- Enclosure: BC400 form factor (mountable) :contentReference[oaicite:11]{index=11}
Conclusion
In applications where more power or more outputs are needed, the **AL600ULACM** steps up to meet higher demands while maintaining the integration and reliability of its smaller counterpart. Whether powering multi-door installations or delivering flexible switching and backup support, this unit is a capable backbone for complex access control systems.
