Magnetic AutoControl ACCPRO-L-LC02040 Left-Hand Barrier Gate w/ 20' VarioBoom Arm (White)

Overview

The Magnetic AutoControl ACCPRO-L-LC02040 is a heavy-duty left-handed barrier gate opener designed for extra-wide lanes at industrial sites, residential buildings, and small parking areas. The unit ships with a 20 ft VarioBoom barrier arm featuring a foam edge for pedestrian protection and improved visibility. The MHTM MicroDrive maintenance-free motor combines the motor, motor control, and gearing into one compact drive unit, delivering high torque performance in severe weather conditions including heavy wind and snow. The white powder-coated aluminum housing measures 12" x 14" x 36" and weighs 88 lbs without the boom.

Key Features

• MGC Pro controller with LCD display for easy configuration
• Programmable I/O and selectable auto-open on power failure
• EN 13849 compliant control unit
• Adjustable opening and closing times
• 4.0-second open and close speeds
• Integrated dual-channel loop detector
• Maximum power consumption of 25W
• Rated for 10 million opening and closing cycles
• IP 54 protection class
• UL & CSA certified
• 2-year warranty
• Note: Booms over 15 ft must use a pendulum support or support post

Specifications

• Included Arm Length: 20 ft
• Opening/Closing Speed: 4.0 seconds
• Cycle Rating: 10 million cycles
• Drive Technology: MHTM MicroDrive maintenance-free motor
• Dimensions (W x D x H): 12" x 14" x 36"
• Weight (without boom): 88 lbs
• Max Power Consumption: 25W
• Protection Class: IP 54
• Temperature Range: -22°F to +122°F
• Input Voltage: 110/115/120 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase)
• Frequency: 50/60 Hz
• Certifications: UL & CSA, EN 13849
• Color: White

The Magnetic AutoControl ACCPRO-L-LC02040 delivers reliable, high-cycle barrier gate control for demanding access applications.
