Magnetic AutoControl ACCPRO-L-LC01540 Left-Hand Barrier Gate w/ 15' VarioBoom Arm (White)

Overview

The Magnetic AutoControl ACCPRO-L-LC01540 delivers reliable access control for wide lanes across industrial sites, residential buildings, and small parking areas. At its core is the MGC Pro control unit, paired with an MHTM MicroDrive maintenance-free motor that provides high torque performance even in severe weather conditions. The motor, motor control, and gearing are all combined in one compact drive unit. The included 15 ft VarioBoom features a foam edge for pedestrian protection and is finished in white for high visibility.

Key Features

• MGC Pro Controller with LCD display, programmable I/O, and selectable auto-open on power failure
• EN 13849 compliant control unit
• MHTM MicroDrive maintenance-free drive unit with high torque
• 4.0-second open and close speeds with adjustable opening and closing times
• Integrated dual-channel loop detector
• 15 ft VarioBoom with foam edge for pedestrian protection
• White powder-coated aluminum housing
• Rated for 10 million opening and closing cycles
• 2-year warranty
• Maximum power consumption of 25W

Specifications

• Included Arm Length: 15 ft
• Opening/Closing Time: 4.0 seconds
• Cycle Rating: 10 million cycles
• Drive Technology: MHTM MicroDrive maintenance-free motor
• Dimensions (W x D x H): 12" x 14" x 36"
• Weight (without boom): 88 lbs
• Input Voltage: 110/115/120 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase)
• Max Power Consumption: 25 W
• Frequency: 50 / 60 Hz
• Protection Class: IP 54
• Temperature Range: -22°F to +122°F
• Certifications: UL & CSA

The Magnetic AutoControl ACCPRO-L-LC01540 is built to perform cycle after cycle — order yours today for dependable, wide-lane access control.
