Magnetic AutoControl ACCXXL-RA03340 Right-Hand Barrier Gate w/ 33' MicroBoom Arm (White)
The ACCXXL-RA03340 is a right-hand Access XXL barrier operator with an included 33 ft MicroBoom XL arm, MGC Pro controller, and integrated 2-channel loop detector. 8.0s operation, 247 lb, IP 54.
Overview
The Magnetic AutoControl ACCXXL-RA03340 is a right-hand Access XXL barrier gate operator engineered for extra-wide lane access control at commercial, industrial, and institutional sites. It ships with a 33 ft MicroBoom XL arm with a protective foam edge, in a white powder-coated aluminum housing. The Access XXL pairs the maintenance-free MHTM MicroDrive with the MGC Pro controller and an integrated 2-channel loop detector.
Key Features
- 33 ft MicroBoom XL arm (included) with protective foam edge
- MHTM MicroDrive maintenance-free drive — motor, motor control, and gearing in one compact unit
- MGC Pro controller with LCD display, EN 13849 compliant, freely expandable
- Integrated 2-channel loop detector for induction loops
- 8.0-second opening/closing, selectable open and close speeds
- 8 digital inputs, 6 relays / 4 digital outputs, variable I/O assignment
- Input for safety light barriers with test
- 100% duty cycle; rated for high-frequency operation
- White powder-coated aluminum housing; IP 54
- Long arms require a support post (AP01) or pendulum support
Specifications
- Model: ACCXXL-RA03340
- Included Arm Length: 33 ft (MicroBoom XL)
- Family Max Barrier Width: 33 ft
- Opening/Closing Time: 8.0 seconds
- Duty Cycle: 100%
- Max Power Consumption: 30 W
- Drive Technology: MHTM MicroDrive
- Control System: MGC Pro
- Voltage: 85–264 VAC, 50/60 Hz
- Housing Dimensions (L x W x H): 17.1" x 14.2" x 46"
- Enclosure Rating: IP 54
- Temperature Range: -22°F to +131°F
- Weight: 247 lb
- Standard Colors: Orange (RAL 2000), White (RAL 9010)
- Barrier Arm Type: MicroBoom XL
- Configuration: Right-hand
What's Included
- Access XXL barrier gate operator (right-hand)
- 33 ft MicroBoom XL arm with foam edge
- MGC Pro controller with integrated 2-channel loop detector
- White powder-coated aluminum housing
Note: Long-span arms require a support post (AP01) or pendulum support per Magnetic engineering limits.
Order the ACCXXL-RA03340 for reliable extra-wide lane barrier control.
