Linear ACT-31DH 1-Button Key Ring Transmitter with HID Proxi
The Linear ACT-31DH (ACP00957) is a 1-Channel Factory Block Coded Key Ring TRANS PROX Transmitter with a built-in 26-bit Wiegand HID-Compatible Proximity Tag, designed for use with Linear's access control products.
Overview
The Linear ACT-31DH is a 1-Channel Factory Block Coded Key Ring TRANS PROX Transmitter and 26-bit Wiegand HID-Compatible Proximity Tag designed for use with Linear's access control products. It combines a radio frequency transmitter and a proximity tag in a single key ring device, eliminating the need for a separate proximity card or tag. The unit ships with a quick-disconnect key ring and lithium batteries rated for a five-year service life.
The ACT-31DH utilizes Linear's MegaCode format, with each transmitter factory preprogrammed with one of over 1,000,000 unique codes, virtually eliminating the possibility of code duplication. Because the receiver learns each specific code, no unauthorized person can gain access by reprogramming a transmitter.
The built-in 26-bit Wiegand HID-Compatible proximity tag is programmed to the same block code as the transmitter. Waving the transmitter near a compatible reader will request access from the system.
Key Features
- Compatible with all Linear access receivers and controllers
- Built-in 26-bit Wiegand proximity tag, interoperable with certain HID® 125-kHz proximity card formats
- Eliminates the need for a separate proximity card or tag and transmitter
- 10-second time-out feature prevents continuous transmission and protects against system shutdown if stuck in transmit mode
- Pre-programmed with the same facility and ID codes for both the transmitter and proximity tag
- Factory block coded — transmitters can be locally or remotely programmed into a Linear access controller by entering the first and last codes of the block
- Facility codes can be selected to further customize the system
- Supplied with a convenient quick-disconnect key ring
- Includes lithium batteries rated for a five-year service life
- Sold in lots of 10
Specifications
- Part Number: ACP00957
- RF Frequency: 318 MHz
- Code Format: Factory block coded in MegaCode format
- Proximity Tag: 26-bit Wiegand HID-Compatible
- Power: Two 2016 batteries
- Dimensions: 1.25" W x 2.25" H x .48" D
Compatibility
- Compatible with all Linear access receivers and controllers
- Proximity tag is compatible with Linear's Model AM-DPR Proximity Reader
The Linear ACT-31DH (ACP00957) delivers a reliable, two-in-one credential solution for professional access control installations.
