Linear ACP00958 4-Channel Key Ring Transmitter with HID Prox
The Linear ACT-34DH (ACP00958) is a 4-channel factory block coded key ring transmitter with a built-in 26-bit Wiegand HID Compatible proximity tag, supplied with a quick-disconnect key ring and lithium batteries with a five-year service life.
Overview
The Linear ACT-34DH (ACP00958) is a 4-Channel Factory Block Coded Key Ring TRANS PROX Transmitter & 26-bit HID Compatible Proximity Tag designed for use with Linear's access control products. The device is supplied with a quick-disconnect key ring and includes lithium batteries with a five-year service life. A unique 10-second time-out feature prevents the system from being shut down by a single transmitter transmitting continuously.
The ACT-34DH includes a 26-bit Wiegand HID Compatible proximity tag programmed to the same block code as the transmitter, eliminating the need for a separate proximity card or tag. Waving the transmitter near a compatible reader will request access from the system.
The transmitter uses MegaCode format, meaning each unit is factory preprogrammed with one of over 1,000,000 codes, virtually eliminating the possibility of code duplication. Because the receiver learns each specific code, no unauthorized person can gain access by reprogramming a transmitter.
Key Features
- Compatible with all Linear access receivers and controllers
- Built-in 26-bit Wiegand proximity tag interoperable with certain HID® 125-kHz proximity card formats
- Eliminates the need for a separate proximity card or tag and transmitter
- Same facility and ID codes for transmitter and proximity tag
- Supplied with quick-disconnect key ring
- MegaCode format — factory preprogrammed with one of over 1,000,000 unique codes
- 10-second time-out feature protects against system shutdown by continuous transmission
- Block coded transmitters can be locally or remotely programmed into memory via first and last codes of the block
- Facility codes can be selected to further customize the system
- Sold in lots of 10
Specifications
- Channels: 4
- RF Frequency: 318 MHz
- Code Format: Factory block coded in MegaCode format
- Proximity Tag: 26-bit Wiegand HID Compatible
- Power: Two 2016 batteries
- Battery Life: Five-year service life
- Dimensions: 1.25" W x 2.25" H x .48" D
- Part Number: ACP00958
Compatibility
- Compatible with all Linear access receivers and controllers
- Proximity tag compatible with the Linear Model AM-DPR Proximity Reader
The Linear ACT-34DH (ACP00958) delivers dual-function convenience by combining a MegaCode transmitter and a 26-bit HID Compatible proximity tag in a single key ring device for streamlined access control deployments.
