NICE North America 912L-2 Swing Gate Actuator
The NICE North America 912L-2 is a newly designed 12V DC actuator for swing gates up to 20 feet long and 600 lbs, featuring a mechanical release mechanism, nonrotating extension tube, and modular design.
Overview
The NICE North America 912L-2 is a newly designed 12V DC replacement actuator built for swing gates up to 20 feet long and 600 lbs. Its modular construction makes repairs straightforward, and it supports both push open and pull open installations. The 912L-2 kit includes a 42-foot harness, mounting hardware, and pivot arm necessary for installation. It can be added to the TITAN12L or TITAN12L1 single gate operators for dual gate functionality.
Key Features
- Mechanical release mechanism with key-lock manual release
- Nonrotating extension tube for consistent operation
- Modular design that is easily repaired if necessary
- Motor encoder included
- Drive mechanism: Stainless Steel Screw
- Easily positioned limit switches
- Supports push open and pull open installation
- Solar compatible
- UL 325 Certified/Listed
- Kit includes 42-foot harness, mounting hardware, and pivot arm
Specifications
- Input Voltage: 12V DC
- Maximum Swing Gate Length: 20 ft
- Maximum Swing Gate Weight: 600 lbs
- Maximum Degree of Opening: 120°
- Operating Temperature: 4°F to 122°F
- Weight: 19.75 lbs
- Dimensions Fully Retracted: 43"L x 4"W x 6.75"D
Compatibility
- Operator Compatibility: Apollo Titan12L1
- Control Board Compatibility: Mercury 310 Control Board, 936 Control Board, 1050 Control Board
The NICE North America 912L-2 is a reliable replacement actuator designed to integrate seamlessly with compatible NICE North America TITAN swing gate systems.
