Maximum Controls Aeromax 100 Indoor Wireless Intercom Desktop
Maximum Controls Aeromax 100 indoor long-range wireless intercom desktop unit with full-duplex audio, 900 MHz technology, and communication range up to 4000 ft line of sight.
Maximum Controls Aeromax 100 Indoor Long-Range Wireless Intercom Desktop Unit
The Aeromax 100 is Maximum Controls' indoor long-range wireless intercom desktop unit. It delivers super-clear hands-free full-duplex audio communication up to 4000 ft (direct line of site) using powerful 900 MHz (1000 mW) technology originally used for military applications. The signal can penetrate through buildings, trees, walls, and any weather conditions. Works with all electric gate openers and combines with outdoor Aeromax models 200 and 200K.
Application Use
Residential, Ranch, Commercial, Industrial
Key Features
- Full-duplex speakerphone with background noise immunity
- Dual "strike" relays for controlling two independent access points
- "Request-To-Exit" (RTE) switch support
- Standard stainless steel housing
- Multiple outdoor and indoor units can be utilized within a facility
- Each outdoor unit can be assigned a unique "access point ID"
- Aux input port for "auto calling" inside unit after detecting a vehicle at entry way
- Designed to easily utilize solar panels for power in remote wire-free applications
- Long-range audio communication: up to 4000 feet (direct line of site)
- Robust 900 MHz (1000 mW) radio communication with excellent interference immunity against walkie-talkies, cell phones, pagers, and handsets
- Reliable wireless performance with secure communication link and proprietary encryption
- 10 selectable channels for cross-talk immunity between adjacent facilities
- Simple "dashboard-like" interface that visually guides installer
- Signal QUALITY LED (bar graph) — indicates radio range performance
- Signal LEVEL LED (multi-color) — indicates radio signal strength
- Status LEDs for each terminal for easy installation and troubleshooting
- Built-in lightning protection on ALL terminals — immune to 20KVolts, 10KAmps surges
- Two different choices for indoor wireless intercoms: surface mount indoor enclosure or desktop unit
- Made in USA — FCC approved
- 2-year warranty
Specifications
- Frequency: 900 MHz (1000 mW)
- Range: Up to 4000 ft (direct line of site)
- Operating Temperature Range: -40 to +158°F
- Lightning Protection: 20KVolts, 10KAmps
- Selectable Channels: 10 (0–9)
Compatibility
Works with all electric gate openers (Apollo, Chamberlain, etc.). Combine with outdoor Maximum Controls Aeromax 200 and Aeromax 200K units.
Easy Installation
- Install power transformer
- Adjust speaker volume
- Select radio channel (0–9)
- Select relay strike time
- Select access point number
- Check radio range signal
- Connect contact inputs
- Connect relay terminals
The Maximum Controls Aeromax 100 is a Made in USA, FCC-approved wireless intercom solution backed by a 2-year warranty for reliable, long-range access communication.
