Maximum Controls Aeromax 100S Indoor Wireless Intercom

Maximum Controls Aeromax 100S Indoor Long-Range Wireless Intercom Surface-Mount Unit

The Aeromax 100S is Maximum Controls' indoor long-range wireless intercom surface-mount unit. It is capable of long-range audio communication up to 4000 ft (direct line of site). Super-clear hands-free full duplex audio is based on 900 MHz (1000mW) technology, which is used for military application and can penetrate through buildings, trees, walls, and any weather conditions. Works with all electric gate openers. Combine with outdoor Aeromax models 200 and 200K.

Application Use

Residential, Ranch, Commercial, Industrial

Key Features

• Full-duplex speakerphone with background noise immunity
• Dual "strike" relays for controlling two independent access points
• "Request-To-Exit" (RTE) switch support
• Standard stainless steel housing
• Multiple outdoor and indoor units can be utilized within a facility
• Each outdoor unit can be assigned a unique "access point ID"
• Aux input port for "auto calling" inside unit after detecting a vehicle at entry way
• Designed to easily utilize solar panels for power in remote wire-free applications
• Long range audio communication: up to 4000 feet (direct line-of-site)
• Robust radio communication with excellent interference immunity against walkie-talkies, cell phones, pagers, and handsets — 900 MHz technology (1000 mW)
• Reliable wireless performance: secure communication link with proprietary encryption
• 10 selectable channels for cross-talk immunity between adjacent facilities
• Simple "dashboard-like" interface that visually guides installer
• Signal QUALITY LED (bar graph) — indicates radio range performance
• Signal LEVEL LED (multi-color) — indicates radio signal strength
• Status LEDs for each terminal — for easy installation & troubleshooting
• Built-in lightning protection on ALL terminals — immune to 20KVolts, 10KAmps surges
• Two different choices for indoor wireless intercoms: surface mount indoor enclosure or desk top unit
• Two different choices for outdoor wireless intercoms: one with keypad, one without
• Made in USA — FCC approved
• 2-year warranty

Specifications

• Operating Temperature Range: -40 to +158°F
• Radio Frequency: 900 MHz (1000 mW)
• Range: Up to 4000 ft (direct line of site)
• Selectable Channels: 10
• Lightning Protection: 20KVolts, 10KAmps

Compatibility

Works with all electric gate openers. Designed to combine with outdoor Aeromax models 200 and 200K.

Easy Installation

• Install power transformer
• Adjust speaker volume
• Select radio channel (0-9)
• Select relay strike time
• Select access point number
• Check radio range signal
• Connect contact inputs
• Connect relay terminals

The Maximum Controls Aeromax 100S delivers reliable, long-range wireless intercom communication backed by a 2-year warranty and Made in USA quality.
