AES OPYN-4G-IBK-US 4G LTE Video Intercom with Keypad
The AES OPYN-4G-IBK-US is a 4G LTE video intercom with integrated keypad, featuring 1080p HD camera, IP54 weatherproof housing, and dual relay outputs for smart, remote access control.
Overview
The AES OPYN-4G-IBK-US delivers high-performance video intercom and access control over 4G LTE — no Wi-Fi required. Built for outdoor use with an IP54-rated, black powder-coated enclosure with hood, it operates reliably across a wide temperature range of -4°F to 131°F (-20°C to +55°C). Surface-mounted and powered at 24VDC, this unit combines HD video, keypad entry, QR code access, and app-based remote management in a single compact device.
Key Features
- 4G LTE connectivity for reliable access control where Wi-Fi is unavailable
- 1080p HD camera with 130° H / 70° V / 150° diagonal field of view and IR night vision
- Opyn App for real-time video monitoring and remote relay activation
- 12-key illuminated keypad supporting up to 150 unique access codes with programmable validity
- QR code scanning with timed or usage-limited access — up to 150 QR codes
- Dual relays (N.O. and N.C.) rated 3A @ 30VDC / 250VAC for controlling two entry points
- Motion detection alerts with event log and video playback
- Voice control compatibility with Alexa and Google Home
- Unlimited user sharing via QR code or app login
- Tamper alarm for enhanced security
- 8GB microSD card included; supports up to 128GB
- UL/ETL certified
Specifications
- Model: OPYN-4G-IBK-US
- Connectivity: 4G LTE
- Power Supply: 24VDC / 2A or 48V PoE
- Power Consumption: 300mA (dialing), 2A peak
- Camera Resolution: 1080p with IR night vision
- Camera Field of View: 130° H / 70° V / 150° diagonal
- Enclosure Rating: IP54
- Finish: Black powder-coated with hood
- Mounting Type: Surface Mounted
- Dimensions: 3.8" W × 7.6" H × 2" D
- Operating Temperature: -4°F to 131°F (-20°C to +55°C)
- Relay Output: 2x (N.O. and N.C.), 3A @ 30VDC / 250VAC
- Storage: 8GB microSD included (up to 128GB supported)
- UL/ETL Certified: Yes
The AES OPYN-4G-IBK-US is a complete 4G LTE video intercom solution engineered for secure, app-connected entry management in locations where traditional wired or Wi-Fi infrastructure is limited.
