Alarm Controls 1200S Magnetic Lock
The Alarm Controls 1200S is a bracket-mounted magnetic lock delivering 1,200 lbs of holding force at 12 or 24 VDC, compatible with any access control system and suitable for interior or exterior applications.
Overview
The Alarm Controls 1200S is a bracket-mounted magnetic lock offering 1,200 lbs of holding force. Operating at 12 or 24 VDC (field selectable), it is designed for high-use areas and suits both interior and exterior applications for traffic control. The E-Z mount header bracket and installation template are included, requiring no special tools. The 1200S carries a limited lifetime warranty and features a clear anodized (US28) finish as standard.
Key Features
- 1,200 lbs holding force
- 12 or 24 VDC, field selectable
- Built-in arc suppression
- Instant release, no hysteresis
- Self-drilling TEC screws included
- Non-aluminum parts plated to resist corrosion
- E-Z mount header bracket and template included — no special tools required
- Compatible with any access control system
- Clear anodized (US28) finish standard
- Available with LED, bond sensor, and door status signalling options
- Limited lifetime warranty
Specifications
- Holding Force: 1,200 lbs
- Voltage: 12 or 24 VDC, field selectable
- Current Draw: 505 mA at 12 VDC; 260 mA at 24 VDC
- Magnet Size: 10-1/2" L x 2-7/8" H x 1-1/2" W
- Armature Size: 7-1/4" L x 2-3/8" H x 5/8" W
- Bond Sensor Relay: SPDT 3A relay contacts (1200LB bond sensor option)
- Operating Temperature: +14°F to +131°F [-10°C to +55°C]
Certifications & Listings
- UL 294 Listed
- UL 10C Fire Rated
- CAN/ULC-S104 Fire Door Conformant
- ULC-S527 Listed
- UL 864 Listed
Options
- DURO Duranodic finish (US40) available — add DURO to end of part number when ordering
- Dress covers available in polished chrome and brass — see Magnetic Lock Accessories for options
The Alarm Controls 1200S is a certified, high-holding-force magnetic lock built for demanding access control installations.
