Alarm Controls 1200WP Weather Resistant Magnetic Gate Lock

Overview

The Alarm Controls 1200WP is a weather resistant magnetic gate lock built for perimeter access control. Enclosed in a completely sealed stainless steel case with a clear anodized (US28) finish, non-aluminum parts are plated to resist corrosion — making the 1200WP a durable choice for outdoor sliding or swinging gate installations. Backed by a limited lifetime warranty.

Key Features

• Up to 1,200 lbs of holding force
• Completely sealed in stainless steel case
• Clear anodized (US28) finish standard
• 12 or 24 VDC, field configurable
• Non-aluminum parts plated to resist corrosion
• 0.5" ID / 0.75" OD conduit fitting pipe thread
• 10" color coded wire leads in plastic jacket
• Blind nuts provided
• Self-drilling TEC screws included
• Top mount or side mount with L brackets (order separately)
• Ideal for sliding or swinging gates
• Limited lifetime warranty

Specifications

• Holding Force: Up to 1,200 lbs
• Magnet Size: 9-1/16" L x 2-5/8" H x 1-1/16" W
• Armature Size: 7-9/32" L x 2-5/8" H x 5/8" W
• Voltage: 12 or 24 VDC, field configurable
• Current Draw: 500 mA at 12 VDC / 250 mA at 24 VDC
• Operating Temperature: +14°F to +131°F [-10°C to +55°C]

Compatible Accessories

• AM6320 — Angle Bracket for 600 and 1200 Series Magnetic Locks, 1-1/2" x 1"
• AM6370 — Three Piece Z Bracket for 1200 Series Single Magnetic Lock

The Alarm Controls 1200WP delivers reliable, weather resistant electromagnetic locking for demanding perimeter gate applications.
