Alarm Controls SREX-100 Active Focused Infrared REX Sensor

Overview

The Alarm Controls SREX-100 is an active focused infrared motion sensor specifically designed for request to exit applications. Its adjustable narrow activation zone provides precise detection, and the sensor cannot be deceived by objects placed under the door.

Key Features

• Active focused infrared detection tailored for REX applications
• Adjustable narrow activation zone
• Not susceptible to defeat by objects placed under the door
• Auto-sensing power input accepts 12 or 24 VAC or VDC
• DPDT relay with 2A contacts
• 14 pin connector with 4 ft of cable included

Specifications

• Power: 12 or 24 VAC or VDC, auto sensing
• Current Draw: 155 mA
• Relay: DPDT with 2A contacts; rated 1.3A at 30 VDC or 24 VAC
• Connector: 14 pin with 4 ft of cable
• Operating Temperature: 32°F to 120°F (0°C to 49°C)
• Certifications: UL 294 listed; CAN/ULC-S319 listed as an access control device

The Alarm Controls SREX-100 delivers reliable, focused infrared request to exit detection for professional access control installations.
